Durable Tool High Homogenization Planetary Mixer Pmc500 Replaceable mixing blades
OPTIONS
Weighing system
According to different requirements we can add aggregate weigher, cement weigher and water weigher.
Temperature and moisture sensor
To ensure concrete and prefabricated parts quality, sensors of temperature and moisture made in Bikotronic of German can be selected
Hydraulic Coupling
High Pressure Washing System
The Skip Hopper
Skip hopper can be chosen according to the requirements of customers.
The feeding door automatically opens when feeding, and closes when the hopper begins to descend.
The device effectively prevents the dust overflow the trough during the mixing to protect the environment.
Principle of Motion: Mixing with no hidden corners in the mixing pan by installing mixing tools and scraper tools on a specially designed drive system.
The mixing track are as follows.
Maintaining Door
The safety control device ensures that the mixer will not start during maintenance.
Large size maintaining door for easy maintenance and cleaning.
Discharging Door
The limited switch installed, can be convenient to set the size of the door according to the need. At most three discharge doors can be opened.
According to the material situation, different device can be selected to make the stirring speed faster, and the stirring is more uniform, without the phenomenon of stacking.
Hydraulic Unit
The hydraulic discharging system is equipped with manual door opener, which can be opened manually in case of power failure.
| Technical Data | ||||||||||||||
| PMC50 | PMC 100 | PMC 150 | PMC 250 | PMC 330 | PMC 500 | PMC 750 | PMC 1000 | PMC 1500 | PMC 2000 | PMC 2500 | PMC 3000 | PMC 4000 | PMC 4500 | |
| Output capacity(L) | 50 | 100 | 150 | 250 | 330 | 500 | 750 | 1000 | 1500 | 2000 | 2500 | 3000 | 4000 | 4500 |
| Input capacity(L) | 75 | 225 | 375 | 500 | 750 | 1125 | 1500 | 2250 | 3000 | 3750 | 4500 | 6000 | 6750 | |
| Input capacity(kg) | 120 | 360 | 600 | 800 | 1200 | 1800 | 2400 | 3600 | 4800 | 6000 | 7200 | 9600 | 10800 | |
| Diameter of Mixing Tank(mm) | 1300 | 1540 | 1900 | 2192 | 2496 | 2796 | 3100 | 3400 | 3400 | |||||
| Mixing Power kw | 3 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 55 | 75 | 90 | 110 | 160 | 200 |
| Blade QTY | 1/2 | 1*2 | 1*2 | 1*2 | 1*2 | 1*2 | 1*3 | 2*2 | 2*2 | 3*2 | 3/6 | 3/9 | 3/9 | 3/9 |
| Side Scraper QTY | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Bottom Scraper QTY | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 2 | 2 | 2 | 2 |
| Weight(kg) | 700 | 1000 | 1200 | 1700 | 2000 | 3500 | 6000 | 7000 | 8500 | 10500 | 11000 | 16000 | 18000 | |
|
|
