Polyurethane Material Planetary Concrete Mixer PMC1000 High-Speed Operation
Features of Planetary mixer
Planetary mixer is a new type of high efficiency, stirring without
dead corner equipment; it has a unique form of stirring. Planet
drive the two stirring shaft turns around the material barrel, at
the same time, the stirring shaft is high-speed operation, so that
the material is strong shearing action, achieve full dispersion and
mixing effect. In addition to the equipment within the knife
scraping wall around the cylinder axis rotation, will be stuck on
the wall material scraping and then put them into mixing shear,
that make no residual material in the mixer and mixing effect is
more ideal. Cylinder with special seal structure and have the
pressure or vacuum stirring. Mixer has good deaeration effect, the
cylinder body can be designed to be heated or cooled according to
customers' needs. The cover is hydraulic lifting, convenient to
operate and clean and the cylinder body can move freely.
The performance characteristics of Mixer
1. Reasonable design and performance optimization of the whole machine
2. Convenient use and maintenance;
3. Firm and reliable, life factory;
4. Good mixing quality and high efficiency
5. Convenient operation and fast discharging speed
6. Low energy consumption and low noise
Hydraulic System Maintenance Instruction
1. ISO-UNI HM46 hydraulic oil is recommended. Fill the oil to two thirds level of the indicator.
2. Before starting the hydraulic system, ensure nobody inside the machine and all he manual valves have been switched off;
3. The pressure of flood valve has been strictly adjusted to standard. Non-professional persons are forbidden to adjust the pressure;
4. Switch off the auto-control loop while using manual hydraulic system. Turn on manual stop valve and pull switching handle on the manual pump to the utmost. Then pull the handle to open the discharge door. Pull the handle in reverse to close the discharge door;
Principle of Motion: Mixing with no hidden corners in the mixing pan by installing mixing tools and scraper tools on a specially designed drive system. The mixing track as follows.
| Technical Data | ||||||||||||||
| PMC50 | PMC 100 | PMC 150 | PMC 250 | PMC 330 | PMC 500 | PMC 750 | PMC 1000 | PMC 1500 | PMC 2000 | PMC 2500 | PMC 3000 | PMC 4000 | PMC 4500 | |
| Output capacity(L) | 50 | 100 | 150 | 250 | 330 | 500 | 750 | 1000 | 1500 | 2000 | 2500 | 3000 | 4000 | 4500 |
| Input capacity(L) | 75 | 225 | 375 | 500 | 750 | 1125 | 1500 | 2250 | 3000 | 3750 | 4500 | 6000 | 6750 | |
| Input capacity(kg) | 120 | 360 | 600 | 800 | 1200 | 1800 | 2400 | 3600 | 4800 | 6000 | 7200 | 9600 | 10800 | |
| Diameter of Mixing Tank(mm) | 1300 | 1540 | 1900 | 2192 | 2496 | 2796 | 3100 | 3400 | 3400 | |||||
| Mixing Power kw | 3 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 55 | 75 | 90 | 110 | 160 | 200 |
| Blade QTY | 1/2 | 1*2 | 1*2 | 1*2 | 1*2 | 1*2 | 1*3 | 2*2 | 2*2 | 3*2 | 3/6 | 3/9 | 3/9 | 3/9 |
| Side Scraper QTY | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Bottom Scraper QTY | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 2 | 2 | 2 | 2 |
| Weight(kg) | 700 | 1000 | 1200 | 1700 | 2000 | 3500 | 6000 | 7000 | 8500 | 10500 | 11000 | 16000 | 18000 | |
|
|
